Water Control Valve Series
106X Electric Float Control Valve, Electric Remote Float Valve, Automatic Water Make-up Valve for Water Tank, Hydraulic Control Valve for Water Tank Overflow Prevention
DN50-600mm
Execution Standard
GB, JIS, ASTM, BS, GOST, DIN
Drive Type
Manual, pneumatic, electric, hydraulic, electromagnetic, self operated
Application Industry
Building Water Supply & Drainage, Fire Protection Water System, Municipal Water Supply, Industrial Circulating Water, Water Plant Clear Water Tank, Community Water Tank, Sewage Treatment, Hotel & Commercial Building Water System, Mining Water Storage System
Material
Carbon steel A105 cast steel WCB ductile iron QT450 stainless steel 304 316 2205 CF8 CF3M
Model
106X-10Q 106X-16Q 106X-16C 106X-16P 106X-150LB 106X-300LB 106X-5K 106X-10K
106X Electric Remote Control Float Valve is a hydraulic control valve with dual protection of machinery & electric. It automatically fills water for water tanks and fire pools. The electric interlock shuts off the valve to prevent overflow when float pilot fails. Mechanical water level control still works during power failure with low water hammer.
Technical Specifications
Water Control Valve Series
