Water Control Valve Series
Model JD745X Diaphragm Type Multifunctional Water Pump Control Valve, also known as JD745X multifunctional water pump control valve, diaphragm slow-close pump control valve, multifunctional check valve for pump outlet, water hammer absorbing valve and slow-opening & slow-closing control valve
DN40-600mm
Execution Standard
GB, JIS, ASTM, BS, GOST, DIN
Drive Type
Manual, pneumatic, electric, hydraulic, electromagnetic, self operated
Application Industry
Municipal water supply & drainage, high-rise building water supply, fire water supply, water plant pump rooms, industrial and mining circulating water, wastewater treatment, commercial building water supply, power station cooling circulating water
Material
Carbon steel A105 cast steel WCB ductile iron QT450 stainless steel 304 316 2205 CF8 CF3M
Model
JD745X-10Q JD745X-16Q JD745X-10P JD745X-16P JD745X-16C JD745X-25C
Model JD745X Diaphragm Type Multifunctional Water Pump Control Valve is mounted at pump outlet, hydraulically self-operated without external power. It integrates shut-off, non-return and water hammer protection functions. Slow opening and slow closing effectively reduce water hammer impact during pump start and stop and prevent medium backflow to protect pumps and pipelines.
Technical Specifications
